Auto weighing automatic vffs packing machine frozen french fries food packing machine
Applications
This automatic VFFS packing machine with multi head weigher is customized for differernt kinds of solid products like snacks food, potato chips, driy fruit, nuts, beans, grains, sugar, salt, seeds, particles, hardwares ect.weighing, filling, sealing and packing into roll film bags.
Features
- Stainless steel models
- Touch screen interface, easy to use and operate
- PLC controller, ensures ease of operation
- Electronic temperature control
- Servomotor is loaded for double film pulling belt
- Date printer is automatically set
- Mark sensor(Photo eye)for registration film
- Packaging style diversified, back sealing, Gusset Bag, continuous bags, punching,
- etc.Production of bag making, sealing, packing, date printing one time
Machine Details
Main Machine
Integrates film pulling mechanism, bag maker, multi-language touch screen and heat sealing device into one function.
Bag making machine, with double belt servo film pulling device, can make the bag making more flat and beautiful, and can pack 80
bags in a minute at the fastest.
Bag making machine, with double belt servo film pulling device, can make the bag making more flat and beautiful, and can pack 80
bags in a minute at the fastest.
Z-type Material Loading Conveyor
It can be docked to the production line to automatically convey materials for packaging. When the material is not available, it
will automatically pause the work, and after the material is available, it will automatically start the work, saving the cost of
manual loading.
will automatically pause the work, and after the material is available, it will automatically start the work, saving the cost of
manual loading.
Multi-head Combination Scales
Available in 10, 14, and 24 head scale configurations. Ideal for measuring dried nuts, frozen fruits and vegetables,cannabis, fudge, puffed foods, hardware, etc.
Platform Bracket
Allows the operator to stand on the machine to safely check the operation of the multi-head combination scale and cleaning work,
to ensure operator safety.
The scale head is relatively heavy. Adding a platform can reduce the weight borne by the host and ensure the stable operation of
the whole machine.
to ensure operator safety.
The scale head is relatively heavy. Adding a platform can reduce the weight borne by the host and ensure the stable operation of
the whole machine.
other options:
Check weigher/Metal detector
Rotary table
Technical Specification
| Model | ZH-BL10 |
| System Output | ≥ 8.4 Ton/Day |
| Packing speed | 30-70 Bags / Min |
| Packing Accuracy | ± 0.1-1.5g |
| Bag size(mm) | (W) 60-200 (L)60-300 for 420VFFS
(W) 90-250 (L)80-350 For 520VFFS
(W) 100-300 (L)100-400 For 620VFFS
(W) 120-350 (L)100-450 For 720VFFS
|
| Bag type | Pillow bag, standing bag (gusseted), punch, Linked bag |
| Range of measuring (g) | 5000 |
| Thickness of film (mm) | 0.04-0.10 |
| Packing Material | laminated film such as POPP/CPP, POPP/ VMCPP, BOPP/PE,
PET/ AL/PE , NY/PE, PET/ PET,
|
| Power Parameter | 220V 50/60Hz 6.5KW |
