Low Cost Screw Auger Conveyor For Feeding Fruit Powder Flour Tea Powder
Application
ZH-CS2 screw conveyor is developed for conveying powder product, such as milk powder, rice powder, sugar, gourmet powder, amylaceum powder, washing powder, spices, etc.
|
Technical Feature
|
|||
|
1.Vibrating screw feeding conveyor is composed of double motor, feeding motor, vibrating motor and with respective control.
|
|||
|
2.Hopper with vibrator makes material to flow easily, and the size of hopper can be customized.
|
|||
|
3.Hopper is separated from twisting shaft and with reasonable structure and easily loading and unloading.
|
|||
|
4.Hopper with dustproof structure and all the material is made of SS304 except for motor, which won’t be polluted by the dust and powder.
|
|||
|
5. Product releasing with reasonable structure that is easy for scrapped materials and tailing removing.
|
|
Model
|
ZH-CS2
|
|||||
|
Charging Capacity
|
2m3/h
|
3m3/h
|
5m3/h
|
7m3/h
|
8m3/h
|
12m3/h
|
|
Diameter of pipe
|
Ø102
|
Ø114
|
Ø141
|
Ø159
|
Ø168
|
Ø219
|
|
Hopper Volume
|
100L
|
200L
|
200L
|
200L
|
200L
|
200L
|
|
Total Power
|
0.78KW
|
1.53KW
|
2.23KW
|
3.03KW
|
4.03KW
|
2.23KW
|
|
Total Weight
|
100kg
|
130kg
|
170kg
|
200kg
|
220kg
|
270kg
|
|
Hopper Dimensions
|
720x620x800mm
|
1023 ×820×900mm
|
||||
|
Charging Height
|
Standard 1.85M, 1-5M could be designed and manufactured.
|
|||||
|
Charging angle
|
Standard 45degree,30-60 degree are also available.
|
|||||
|
Power Supply
|
3P AC208-415V 50/60Hz
|
|||||
