1. Application:
It’s suitable for weighing slice, roll or regular shape products such as tea, leafs,sugar, salt, seed, rice, sesame, glutamate, milk powder, coffee powder and seasoning powder, etc.
2.Component:
1.Incline elevator: to conveyor the product to the linear weigher
2.Linear weigher: dose the product according to the target weight you set
3.Support: to support the linear weigher
4.Sealer: to heat seal the bag, with adjustable height
3.Main Features:
*High precision digital HBM load cell
*Color touch screen
*Multilanguage choice (Translation is needed for some specific language)
*Different authority management
4. Special Features:
*Weighing mix different products at one discharge
*Parameters can be freely adjusted during running condition
*New generation design, each actuator,boards can exchange with each other.
5.Specification
Specification For linear Weigher
|
|||
Linear weigher just suitable for Sugar,Salt,Seeds,Spices,Coffee,Beans,Tea,Rice,Feedstuff,Small pieces,Pet food and other powder,Small granules,Pellets products.
|
|||
Model
|
ZH-A4 4 heads linear weigher
|
ZH-AM4 4 heads small linear weigher
|
ZH-A2 2 heads linear weigher
|
Weighing Range
|
10-2000g
|
5-200g
|
10-5000g
|
Max Weigh Speed
|
20-40 Bags/Min
|
20-40 Bags/Min
|
10-30 bags/min
|
Accuracy
|
±0.2-2g
|
0.1-1g
|
1-5g
|
Hopper Volume (L)
|
3L
|
0.5L
|
8L/15L option
|
Driver Method
|
Stepper motor
|
||
Interface
|
7″HMI
|
||
Power Parameter
|
Can customized it according to your local power
|
||
Package Size (mm)
|
1070 (L)×1020(W)×930(H)
|
800 (L)×900(W)×800(H)
|
1270 (L)×1020(W)×1000(H)
|
Total Weight(Kg)
|
180
|
120
|
200
|
